Piranhaflex™ Series PF528 100R8 is ideal for general purpose high pressure hydraulic applications with working pressures of 1,000 to 5,000 psi (depending on size). This hose is commonly used in industrial hydraulic construction, material handling, and agricultural equipment. Piranhaflex™ Series PF528NC has an orange, non pin-pricked cover ideal for use in applications where a non-conductive high pressure hydraulic hose is required. Typical applications include: hydraulic tools, lubrication lines and man lifts. Meets or exceeds SAE 100R8 impulse requirements.
Tube: Specialty Grade Nylon
Cover: Orange non-conductive, pin-pricked polyurethane (abrasion resistant)
Reinforcement: Braided high tensile strength fiber
Temperature Range: -40ºF to 200ºF (-40ºC to 93ºC) [for petroleum-based hydraulic fluids]
-40ºF to 140ºF (-40ºC to 60ºC) [for water-based & phosphate ester-based hydraulic fluids]
